ASUS TUF Gaming GeForce RTX 4070 SUPER OC, TUF-RTX4070S-O12G-GAMING, 12GB GDDR6X, HDMI, 3x DP
- Modell
- NVIDIA GeForce RTX 4070 SUPER
- Speicher
- 12GB GDDR6X, 192bit, 21Gbps, 1313MHz, 504GB/s
- Takt Basis
- 1920MHz (Standard-Profil), 1920MHz (OC-Profil)
- Takt Boost
- 2565MHz (Standard-Profil), 2595MHz (OC-Profil)
- Übertaktung
- +120MHz Boost (OC-Profil), +90MHz Boost (Standard-Profil)
- Kühlung
- 3x Axial-Lüfter (95mm) mit 0dB-Zero-Fan-Modus
- TDP/TGP
- 220W (NVIDIA)
- Stromanschlüsse
- 1x 12VHPWR
- Anschlüsse
- 1x HDMI 2.1a, 3x DisplayPort 1.4a
- Anbindung
- PCIe 4.0 x16
- Besonderheiten
- Beleuchtung (RGB), Backplate, AI-Beschleunigung, Taktprofile (Default Mode/OC Mode), Grafikkarten-Halterung (ASUS TUF Graphics Card Holder)
- Gesamthöhe
- Quad Slot (3.15 Slots)
Bitte die EU-Übersicht verwenden oder ggf. die Filterkriterien ändern.
Weitere Varianten (Top-10)
ASUS Dual GeForce RTX 4070 SUPER EVO White OC, DUAL-RTX4070S-O12G-EVO-WHITE, 12GB GDDR6X, HDMI, 3x DP
90YV0KC8-M0NA00ASUS Dual GeForce RTX 4070 SUPER EVO White, DUAL-RTX4070S-12G-EVO-WHITE, 12GB GDDR6X, HDMI, 3x DP
90YV0KC9-M0NA00ASUS Prime GeForce RTX 4070 SUPER, PRIME-RTX4070S-O12G, 12GB GDDR6X, HDMI, 3x DP
90YV0KC6-M0NA00ASUS Prime GeForce RTX 4070 SUPER, PRIME-RTX4070S-12G, 12GB GDDR6X, HDMI, 3x DP
90YV0KC7-M0NA00ASUS ProArt GeForce RTX 4070 SUPER OC, PROART-RTX4070S-O12G, 12GB GDDR6X, HDMI, 3x DP
90YV0KC4-M0NA00ASUS ProArt GeForce RTX 4070 SUPER, PROART-RTX4070S-12G, 12GB GDDR6X, HDMI, 3x DP
90YV0KC5-M0NA00ASUS TUF Gaming GeForce RTX 4070 SUPER, TUF-RTX4070S-12G-GAMING, 12GB GDDR6X, HDMI, 3x DP
90YV0K81-M0NA00ASUS Dual GeForce RTX 4070 SUPER EVO OC, DUAL-RTX4070S-O12G-EVO, 12GB GDDR6X, HDMI, 3x DP
90YV0KC0-M0NA00ASUS Dual GeForce RTX 4070 SUPER EVO, DUAL-RTX4070S-12G-EVO, 12GB GDDR6X, HDMI, 3x DP
90YV0KC1-M0NA00Ähnliche Produkte (Top-10 in PCIe)
ASUS Prime Radeon RX 9070 XT OC, PRIME-RX9070XT-O16G, 16GB GDDR6, HDMI, 3x DP
90YV0L71-M0NA00ASUS ROG Astral GeForce RTX 5090 OC, ROG-ASTRAL-RTX5090-O32G-GAMING, 32GB GDDR7, 2x HDMI, 3x DP
90YV0LW0-M0NA00ASUS Prime GeForce RTX 5070 Ti OC, PRIME-RTX5070TI-O16G, 16GB GDDR7, HDMI, 3x DP
90YV0MF0-M0NA00ASUS Dual Radeon RX 9060 XT, DUAL-RX9060XT-16G, 16GB GDDR6, HDMI, 2x DP
90YV0LG2-M0NA00 / 90YV0LG2-M0AA00ASUS Dual GeForce RTX 5060 Ti OC, DUAL-RTX5060TI-O16G, 16GB GDDR7, HDMI, 3x DP
90YV0MH0-M0NA00ASRock Radeon RX 9070 Challenger 16GB, RX9070 CL 16G, 16GB GDDR6, HDMI, 3x DP
90-GA5NZZ-00UANFMSI GeForce RTX 5090 32G Ventus 3X OC, G5090-32V3C, 32GB GDDR7, HDMI, 3x DP
V530-060RMSI GeForce RTX 5080 16G Gaming Trio OC, G5080-16GTC, 16GB GDDR7, HDMI, 3x DP
V531-005RXFX Swift Radeon RX 9070 XT Triple Fan Gaming Edition, 16GB GDDR6, HDMI, 3x DP
RX-97TSWF3B9Sapphire Pulse Radeon RX 9070 XT, 16GB GDDR6, 2x HDMI, 2x DP, lite retail
11348-03-20G- Modell
- NVIDIA GeForce RTX 4070 SUPER
- Speicher
- 12GB GDDR6X, 192bit, 21Gbps, 1313MHz, 504GB/s
- Takt Basis
- 1920MHz (Standard-Profil), 1920MHz (OC-Profil)
- Takt Boost
- 2565MHz (Standard-Profil), 2595MHz (OC-Profil)
- Übertaktung
- +120MHz Boost (OC-Profil), +90MHz Boost (Standard-Profil)
- Kühlung
- 3x Axial-Lüfter (95mm) mit 0dB-Zero-Fan-Modus
- TDP/TGP
- 220W (NVIDIA)
- Stromanschlüsse
- 1x 12VHPWR
- Anschlüsse
- 1x HDMI 2.1a, 3x DisplayPort 1.4a
- Anbindung
- PCIe 4.0 x16
- Besonderheiten
- Beleuchtung (RGB), Backplate, AI-Beschleunigung, Taktprofile (Default Mode/OC Mode), Grafikkarten-Halterung (ASUS TUF Graphics Card Holder)
- Gesamthöhe
- Quad Slot (3.15 Slots)
- Abmessungen
- 301x139x63mm (LxBxH)
- Bauform
- PCIe-Karte (full height)
- Slotblende
- full height
- AI-Rechenleistung (dense)
- 284 TOPS (FP8), 142 TOPS (FP16)
- AI-Rechenleistung (sparse)
- 568 TOPS (FP8), 284 TOPS (FP16)
- GPU-Rechenleistung
- 37.27 TFLOPS (FP16), 37.27 TFLOPS (FP32), 0.58 TFLOPS (FP64)
- Chip-Daten
- Chip-Architektur
- NVIDIA Ada Lovelace (ab 2022/Q3)
- Chip-Bezeichnung
- AD104 (AD104-350-A1)
- Chip-Ausbau
- 93.3% aktive Recheneinheiten (56/60 SM)
- Chip-Konfiguration
- 56SM (7168SP/224TMU/80ROP), 56 RT-Cores, 224 Tensor-Cores, 48MiB L2-Cache
- Chip-Fertigung
- TSMC N5P [NVIDIA 4N] (5nm)
- Chip-Größe
- 294mm², monolithisch, 35.8 Mrd. Transistoren
- Chip-Funktionen
- Raytracing (3rd Gen NVIDIA RTX), NVIDIA Tensor (4th Gen, 142 TOPS), HDCP 2.3
- Chip-Verwendung
- GeForce RTX 4070 Ti
GeForce RTX 4070 SUPER
GeForce RTX 4070
RTX 4000 SFF Ada
RTX 4000 Ada
L4 - API-Unterstützung
- DirectX 12 Ultimate (12_2) / CUDA 8.9 / Vulkan 1.3 / OpenCL 3.0 / OpenGL 4.6 / Shader Model 6.7
- Transcoding-Engine
- 1x NVENC (8th Gen, max. Sessions: 8), 1x NVDEC (5th Gen), Info
- Encoding
- AV1 (YUV 4:2:0), H.265 (4K YUV 4:2:0 / 4K YUV 4:4:4 / 4K Lossless / 8K / HEVC 10bit support / HEVC B Frame support), H.264 (YUV 4:2:0 / YUV 4:4:4 / Lossless)
- Decoding
- AV1 (8bit / 10bit), H.265 (8bit 4:2:0 / 10bit 4:2:0 / 12bit 4:2:0 / 8bit 4:4:4 / 10bit 4:4:4 / 12bit 4:4:4), H.264 (8bit 4:2:0), VP9 (8bit / 10bit / 12bit), VP8, VC-1, MPEG-2, MPEG-1
- Multi-GPU-Anbindung
- -
- Veröffentlichung (Serie)
- 08.01.2024, Verkaufsstart: 17.01.2024, UVP: 599 USD (NVIDIA)
- Grafik
- NVIDIA GeForce RTX 4070 SUPER - 12GB GDDR6X - Desktop
- Letztes Preisupdate
- -
- Gelistet seit
- 10.01.2024, 12:23
Bewertung für ASUS TUF Gaming GeForce RTX 4070 SUPER OC, TUF-RTX4070S-O12G-GAMING, 12GB GDDR6X, HDMI, 3x DP
Teilen Sie uns Ihre Meinung zu ASUS TUF Gaming GeForce RTX 4070 SUPER OC, TUF-RTX4070S-O12G-GAMING, 12GB GDDR6X, HDMI, 3x DP mit oder lesen Sie die Bewertungen unserer Mitglieder, Experten und anderer Websites zu dessen Varianten.-
techpowerup.com: ASUS GeForce RTX 4070 Super TUF OC Review (translate)
ASUS TUF Gaming GeForce RTX 4070 SUPER OC is the company's premium custom design rendition of the new RTX 4070 SUPER performance segment GPU launched by NVIDIA today. Within the product lineup, ASUS positions the TUF Gaming series above its DUAL OC series, and a notch below the ROG Strix series. The TUF Gaming series, over the past couple of generations, has evolved into a high-quality product design thanks to its industrial looks, and minimal cooler shroud that allows more of the heatsink to be exposed, for greater airflow. The NVIDIA GeForce RTX 4070 SUPER is part of a mid lifecycle refresh of the RTX 40-series Ada, focusing on the higher end of the product stack. The RTX 4070 SUPER starts selling today, and is recommended by NVIDIA for 1440p gaming with maxed out settings, including ray tracing; although in the real world, the RTX 4070 series cards have been tested to be capable of 4K Ultra HD at fairly good frame rates, which you can further improve by spending some time around your game's settings, getting GeForce Experience to find the right ones; or taking advantage of DLSS technologies, including the latest DLSS 3 Frame Generation.
